AFR 215cc LSx Mongoose CNC Cathedral Heads, LS1/LS2 Applications

AFR 215cc LSx Mongoose CNC Cathedral Heads, LS1/LS2 Applications

SKU: AFR-1530

Availability: In stock

Product type: Cylinder Heads

Vendor: Airflow Research

Regular price $2,999.99

Tags:

AFR 215cc LSx Mongoose CNC Cathedral Heads, LS1/LS2 Applications (PAIR)

AFR 215cc LSX Mongoose Strip cylinder heads are strong, versatile, and a great match for aggressive applications and large stroker engines where your aim is enhancing street/strip performance. These aluminum heads have 100 percent CNC-ported chambers, intake and exhaust ports, and use A356 aluminum castings. They are equipped with AFR's 3/4 in. thick deck and thicker port and combustion surfaces. These medium sized, high-velocity torque monsters flow 312 cfm at 0.600 in. of lift and can handle up to 408 cu. in. motors operating at or below 6,500 rpm. With a minimum bore diameter of 3.900 in., AFR 215cc LSX Mongoose Strip cylinder heads offer serious velocity and still provide significant airflow to generate over 500 hp at the crank!

215cc Competition Flow Chart
	.200	.300	.400	.500	.550	.600
Int	149	215	259	293	300	303
Exh	111	150	209	225	230	233

Test conducted at 28" of water (pressure) on Superflow 1020
Bore Size: 4.060", intake 3/4" radius plate exhaust, 1 3/4" curved pipe

Specifications & Features:
Material	A356 Aluminum
Intake Port Volume	215cc
Intake Port Dimension	3.275"H x 1.120"W x5/16 top 3/8 bottom
Intake Port Location	Stock
Exhaust Port Volume	85cc
Exhaust Port Dimension	1.415" H x 1.710" W
Exhaust Port Location	Stock
Combustion Chamber Size	65cc
Valve Cover Bolt Pattern	Center Bolt
Valve Angle	15°
Valve Spring Pocket Diameter	1.510" O.D
Max Valve Spring Pocket Machining	1.525" O.D
Deck Thickness	.750"
Minimum Bore Diameter	3.900"
Flat Mill	.006" per cc 58cc Maximum
Minimum Cross Sectional Area	2.260 sq. in.
Spark Plug Dimensions	14mm x .750" w/Gasket Seat
